Brisa 2000 counterweight ceiling fan in polished copper with mah

BRISA 2000

Like satellites orbiting a planet, the Brisa’s select mahogany blade head and lunar counterweight gently revolve 360° about its spherical gear housing. The fan head can be infinitely positioned in a 180-degree arc for optimum air movement; the greater the angle of the motor to the horizontal support rods (up or down), the faster the axial rotation. A slow, controlled axial rotation is achieved by both fan head position and fan blade speed. Matthews 360° rotational fans circulate heat and air conditioning more efficiently than traditional paddle fans. Constructed of cast aluminum, heavy spun and stamped steel, the Brisa carries a limited lifetime warranty.

Brisa 2000 ceiling fan in matte black with mahogany blades made

FINISHES & OPTIONS

  • Brisa 2000 ceiling fan in Black finish with Metal Blades made by
  • Brisa 2000 ceiling fan in Black finish with Metal Blades in Safe

Fan Heads

Metal
Solid Mahogany Wood

Finishes

Black
Bronzette
Brushed Nickel

Special Finishes

Brushed Brass
Brushed Copper
Polished Brass
Polished Chrome
Polished Copper
Polished Chrome - Damp
Brushed Nickel - Damp
Gloss White
Black Nickel
Agua Marinha
Ametista
Esmeralda
Ouro
Rubi
Safira

Brisa Specifications

Fan Weight21 lbs
Voltage110 or 220
Motor TypeAC
RotationYes
Downrods Lengths. Field cuttable.inches: 5, 10, 20, 30, 48, 72 centimeters: 13, 25, 51, 76, 122, 183
Downrod Diameter.75 inch
Overall Drop10 inches / 25 cm + downrod length
EnvironmentDamp locations for all finishes. Neither coastal, saltwater nor chlorine compatible
AmbienceSoothing White Noise
Safety CertificationUL / CUL
WarrantyLimited Lifetime
Fan Head OptionsSolid WoodMetal with Guard
Fan Diameter40 inches / 102 cm39 inches / 99 cm
Fan Blade Diameter16 inches / 41 cm13 inches / 33 cm
Guard OptionsNo Cage OptionSafety Cage or Decorative Cage
RPM (Low / High)866 / 1336790 / 1205
CFM (Low / High)1602 / 2376790 / 1265
Watts (High)52.4455.15
CFM/Watt (High)45.3122.94
Blade Pitch19°31°
One downrod of 10 inches / 25 cm
Flat ceiling canopy
3-Speed Wall Remote
White Decora-style, 3-speed wall control
Optional Equipment:
29° vaulted ceiling mount and canopy
NOTE: *Unipack Shipping for Wood Blades only
Brisa 2000 Technical Diagram
Technical diagram for Brisa 2000 ceiling fan by Matthews Fan Company
